STU-QMC
STU-QMC is a shield box that contains 4 independent compartments, each compartment is equipped with a test module and one of compartment with built-in PC. It is for base station function verification testing, peak rate testing, etc.
Classification:
STU-QMC
Key Features:
Shielding effects ≥ 70dB
The Unit can fit on a 19 inch's rack
Built-in 4 Qualcomm X55, X62, or X65 modules
Built-in industrial PC
Support connects to Base Station directly by RF feeder or wireless
Support iPerf UL&DL, FTP UL&DL, HTTP, Ping etc.
Support LTE&NR Signaling Collection
Support TA control
Each shield compartments are equipped with heat dissipation holes and fans, effectively solving heat dissipation problems.
